ALUCOMAT® Texture

Introduction

ALUCOMAT® is world’s original ALUminium COmposite MATerial (ACM) Total Solution provider, the material is later known as Aluminium Composite Panel (ACP).


Interior-class ALUCOMAT® Texture

ALUCOMAT® Texture may be made available for Interior use. Similar to its exterior counterpart, Interior Texture also has PET film laminated on outer face imitating the beauty of natural stone, granite, and wooden panels.

Because Interior Wave is PET laminated, it is absolutely not for exterior use.

Specifications

Since ALUCOMAT® is world’s pioneer of aluminium composite panel since 1966, ALUCOMAT® Texture specifications are world specifications:
Alloy 0.15 mm virgin aluminium sheet on each face
Coating Outer face is laminated with PET patterns and lacquered coated with Acrylic coating  for Interior application purposes
Inner face is protected with a service coat (not mill finish)
Core LDPE, RoHS compliant
Thickness 3.00 mm
Width 1,220 mm
Length 2,440 mm
Custom Thickness 3.0 ~ 6.0 mm
             Width 1,250 / 1,500 mm
             Length On demand

Total Solution Family

ALUCOMAT® Texture is more than a piece of panel. It may come with a variety of different alloy types and thickness, as well as coating systems to better suit different application needs. Please select an appropriate one listed on the right menu or directly below:
Variations Alloy Coating System Core Material
Exterior Texture 0.50 mm Next-generation FEVE resin paint from Japan, lacquered coated according to AAMA 2605-05 standards ASTM / BS / DIN certified mineral filled FR

Custom Color & Pattern

Please contact us to Request a Custom Color Matching. Limits applied.

Color Chart

Selected standardized colors are available below for viewing below. Due to color reflection difference on computer monitor, please request actual sample swatch before placing order.

  • Camphor GD325
    Camphor
    GD325
  • Norwegian Rose GD328
    Norwegian Rose
    GD328
  • Jade Green GD329
    Jade Green
    GD329
  • Granite GD342
    Granite
    GD342
  • Hickory GD397
    Hickory
    GD397
